MODEL# | EC MPPT V3-V4 | |
POWER | 60Amp | |
Solar System Voltage | 12V/24V | |
PV | Operation Voltage | 15-85Vdc @12V 34-85Vdc @24V |
Max. PV open circuit voltage | 90V-DC | |
Max. PV input power | 12V 1000W / 24V 2000W | |
Max. charging current | 60A | |
Conversion Efficiency | 98% | |
Protection | High voltage, high temperature protection | |
BATTERY | Battery Type | Lead Acid, Tubular, AGM |
Charging Algorithm | 3-stage: Bulk, Float, Trickle | |
Equalize charge voltage | 14.7v | |
Output volt without Battery | 12V:14.2V 24V:29V | |
COOLING | FAN THERMALLY CONTROLLED |
Package included:
1 x Solar MPPT Controller
